ME 16C NTChemistry diaphragm pump
Overview
- outstanding chemical resistance and superior vapor tolerance
- very high pumping speed even at low vacuum levels
- compact design
- whisper quiet and very low vibration
- long diaphragm life, maintenance-free drive system
Ultimate vacuum
70 mbar
Ultimate vacuum with gas ballast
100 mbar
Max. pumping speed 50 Hz
16.3 m3/h
Chemistry diaphragm pump in action
Chemistry diaphragm pumps of the NT design are an excellent solution for continuous, oil-free pumping of corrosive gases and vapors. The one-stage construction provides the advantageous combination of high pumping speed and low ultimate vacuum down to 70 mbar. All parts in contact with pumped media are made of chemically resistant fluoroplastics. Well-proven PTFE sandwich diaphragms increase reliability and extend operating life. The chemistry vacuum system ME 8C NT +2AK with inlet separator to protect the pump against particles and liquid droplets and outlet separator to collect condensate is a well-proven choice for demanding applications. The eight-cylinder pump ME 16C NT provides a particularly high performance together with a compact design. Accessories such as inlet separator (AK) for protection of the pump and exhaust vapor condenser (EK) for solvent recovery can be mounted on this pump later, if the need arises. Eight-cylinder NT pumps feature quiet operation, smooth and easy to clean surfaces. Large one-stage chemistry diaphragm pumps are an excellent choice for pumping large amounts of gases and vapors. They do not consume water and therefore do not produce any contaminated waste water. Typical applications are filtration networks and in general evaporation of low boiling solvents. The ME 16C NT is an excellent choice for processes with large gas flow at high process pressures. It can easily be upgraded with accessories like inlet separator (AK) for challenging applications and an exhaust vapor condenser (EK) for solvent recovery.
Technical data and graphs
Max. pumping speed 50 Hz | 16.3 m3/h | Select diagram |
Max. pumping speed 60 Hz | 9.6 cfm | Select diagram |
Ultimate vacuum | 70 mbar / 53 torr | |
Ultimate vacuum with gas ballast | 100 mbar / 75 torr | |
Number of heads | 8 | |
Number of stages | 1 | |
Lower ambient temperature (operation) | 10 °C | |
Upper ambient temperature (operation) | 40 °C | |
Lower ambient temperature (storage) | -10 °C | |
Upper ambient temperature (storage) | 60 °C | |
Max. back pressure (abs.) | 1.1 bar | |
Inlet connection | small flange KF DN 25 | |
Outlet connection | Hose nozzle DN 15 mm | |
Rated motor power | 0.53 kW | |
Rated motor speed at 50/60 Hz | 1650 min-1 | |
Protection class | IP 40 | |
Dimension L in mm | 533 mm | |
Dimension W in mm | 260 mm | |
Dimension H in mm | 359 mm | |
Weight | 27.3 kg | |
Noise level at 50 Hz, typ. | 54 dBA | |
NRTL certification | No | |
Items supplied | Pump completely mounted, ready for use, with manual. | |
Rated mains voltage range 1 | 200-230 V | |
Mains frequency 1 | 50-60 Hz |
für Zoom klicken
Max. pumping speed 50 Hz
für Zoom klicken
Max. pumping speed 60 Hz
für Zoom klicken
Pump down graph 50 Hz (100 l volume)
für Zoom klicken
Pump down graph 60 Hz (100 l volume)
Equipment
-
KF DN 25 PTFE-tubing (antistatic) with small flanges
- Nominal width KF DN 25
- Chemically resistant
- Material antistatic
AK 500 / KF DN 25 Inlet separator AK with round bottom flask 500 ml, with connections KF DN 25 and hose nozzle DN 15 mm- Compact and leak-tight
- High conductance
- Easy draining of condensate
KF DN 20/25 C Al/FEP External centring ring- Material sealing FEP
- Material Aluminum
- Nominal width KF DN 20/25 mm
