AK 500 / KF DN 25Inlet separator AK with round bottom flask 500 ml, with connections KF DN 25 and hose nozzle DN 15 mm
Overview
- for all NT diaphragm pumps with flange KF DN 25
- direct mounting at the inlet, compact and leak-tight
- high conductance
- direct visibility of condensate through the coated round bottom flask
- easy draining of condensate
Articleno.
20699979
Inlet separator AK with round bottom flask 500 ml, with connections KF DN 25 and hose nozzle DN 15 mm in action
Inlet separator AK with round bottom flask 500ml, with KF DN 25, for all pumps from ME 16 NT to MV 10C NT
For all NT diaphragm pumps with flange KF DN 25 (all types ME 16(C) NT, MD 12(C) NT, MV 10(C) NT and their pumping units). Inlet with small flange KF DN 25 and hose nozzle DN 15 mm. Separators (AK) protect the vacuum pump at the inlet from particles and liquid droplets. Separators catchpot made of glas with good chemical resistance.Technical data and graphs
| Ambient temp., upper limit, in °C | 40 °C | |
| Ambient temp., lower limit, in °C | 10 °C | |
| Dimension L in mm | 106 mm | |
| Dimension B in mm | 121 mm | |
| Dimension H in mm | 229 mm | |
| Outlet connection | Small flange KF DN 25 / hose nozzle DN 15 mm | |
| Inlet connection | small flange KF DN 25 | |
| For VACUUBRAND pumps | ME 16C NT, MD 12C NT, MV 10C NT | |
| Volume catchpot | 500 ml | |
| Items supplied | Upgrade kit inlet seperator with connections KF DN 25 with high chemical resistance |
