MV 10C EXChemistry diaphragm pump
Overview
- outstanding chemical resistance and superior vapor tolerance
- flame proof motor with integrated, self-locking overload and excess temperature protection for direct 230V / 50Hz single phase power supply. No need for any additional and specific overcurrent protection device
- overpressure safety relief valves internally and at outlet
- safety diaphragm technology with option for inert gas purge and detection of diaphragm breakage
Ultimate vacuum
2 mbar
Ultimate vacuum with gas ballast
10 mbar
Max. pumping speed 50 Hz
8.1 m3/h
Articleno.
20696945
Chemistry diaphragm pump in action
ATEX chemistry diaphragm pumps offer all advantages of oil-free chemistry diaphragm pumps. Typical applications are rotary evaporators and drying ovens with potentially explosive atmospheres. The ATEX approval includes the interior of the pump (in contact with pumped gases) as well as the surrounding area of the pump. All wetted parts of the pumps have excellent chemical resistance and are mainly made of antistatic materials. Included in delivery is a separate gas ballast connection part for use of inert gas.
Technical data and graphs
| Max. pumping speed 50 Hz | 8.1 m3/h | |
| Ultimate vacuum | 2 mbar / 1.5 torr | |
| Ultimate vacuum with gas ballast | 10 mbar / 7.5 torr | |
| Number of heads | 8 | |
| Number of stages | 4 | |
| Vacuum controller | 17 | |
| Lower ambient temperature (operation) | 10 °C | |
| Upper ambient temperature (operation) | 40 °C | |
| Lower ambient temperature (storage) | -10 °C | |
| Upper ambient temperature (storage) | 60 °C | |
| Max. outlet pressure (abs.) | 1.1 bar | |
| Inlet connection | small flange KF DN 25 | |
| Outlet connection | small flange KF DN 16 | |
| Rated motor power | 0.5 kW | |
| Rated motor speed at 50/60 Hz | 1500 min-1 | |
| Protection class IEC 60529 | IP 54 | |
| Dimension L in mm | 560 mm | |
| Dimension B in mm | 430 mm | |
| Dimension H in mm | 410 mm | |
| Weight | 63.2 kg | |
| Noise (sound pressure level) in dBA at 50 Hz or 1500 rpm/62% (VARIO)/1500 rpm (VARIO-SP)/12500 Upm (VACUU·PURE®) | 52 dBA | |
| ATEX conformity | Pumping chamber (pumped gases): II 2G Ex h IIC T3 Gb X, Environment with inert purge gas: II 2G Ex h IIB T4 Gb X, Environment without inert purge gas: II 3G Ex h IIB T4 Gc X, Motor: II 2G Ex db IIB T4 Gb | |
| NRTL certification | No | |
| Items supplied | Pump completely, ready for use, with manual, 2 m cable without plug at each of the two motors. | |
| Rated mains voltage range 1 | 230 V | |
| Mains frequency 1 | 50 Hz |
